BAF‑400V Gantry‑Type 5‑Axis Simultaneous Machining Center
Gantry‑5‑Axis, Direct‑Drive Rocker, Precision Machining For Small‑Medium Complex Parts
BAF‑400V Gantry‑Type 5‑Axis Simultaneous Machining Center
Gantry‑type vertical 5‑axis machine, A/C torque‑motor direct‑drive rocker table, complex‑surface 5‑axis simultaneous machining in one clamping
Key Features
Gantry‑Type High‑Rigidity Bed
Vertical gantry layout, symmetric X/Y guideways, excellent rigidity and stable operation
A/C Torque‑Motor Direct‑Drive Table
Rocker‑type A/C axis torque‑motor direct‑drive, high positioning & repeat accuracy, fast 5‑axis response
Complex‑Surface Scenario Adaptation
Ideal for small‑medium complex‑surface parts such as medical devices, molds and impellers
Technical Specifications
Accessories & Optional Equipments
Standard (Included)
Optional (Extra Cost)
Product Overview
Application Areas
Automotive steering knuckles
Impeller & turbine blades
Hydraulic valve body components
Packaging & Shipping
Packaging
Export-grade IPPC‑fumigated wooden case packaging with waterproof membrane and shockproof foam. Key components (spindle, control system, guideways) receive additional protective wrapping. Photos of the completed packaging are provided before shipment.
Transportation
We arrange sea, land, or air freight based on equipment size and your delivery timeline. Tracking information is shared as soon as the shipment departs. Please note: actual transit time depends on the shipping route and customs clearance, which are outside our direct control — but we monitor every shipment and keep you updated.
Delivery Time
Production lead time: 20-45 working days for standard configuration machines. Customized equipment lead time is quoted per project. Rush production may be available for urgent orders — please contact us to confirm current factory capacity.
After-sales Service
Installation & Commissioning
We provide detailed installation manuals, step-by-step video guides, and live online support from our engineers to help you install and commission your machine correctly. For complex setups, we can arrange a video call with our technical team to guide your local technicians through the process.
Quality Assurance
12 months warranty for the whole machine, covering manufacturing defects under normal use. Core components (spindle, control system) are covered for 24 months. During the warranty period, we provide replacement parts free of charge; shipping costs and local labor are the customer's responsibility. After the warranty expires, we continue to offer paid spare parts and technical advice.
Technical Training
We provide free operation and maintenance training through detailed video tutorials, user manuals, and live online Q&A sessions with our engineers. If you prefer factory training in China, we can arrange it — travel and accommodation costs are the customer's responsibility.
Technical Support
Our technical team responds within one business day (Monday-Friday, China Standard Time) to emails and messages. For urgent issues, we offer remote video diagnosis and troubleshooting. In critical situations, we can coordinate with the factory engineer to provide specialized support; any on-site service requests will be quoted separately.
